Grey Colour AC Generator Load Bank With Multi - Functional Digital Display

Guangdong Fullde Electrical Technology Co., Ltd
Contact Now
    Buy cheap Grey Colour AC Generator Load Bank With Multi - Functional Digital Display from wholesalers

    Buy cheap Grey Colour AC Generator Load Bank With Multi - Functional Digital Display from wholesalers
    • Buy cheap Grey Colour AC Generator Load Bank With Multi - Functional Digital Display from wholesalers

    Grey Colour AC Generator Load Bank With Multi - Functional Digital Display

    Ask Lasest Price
    Brand Name : Fullde
    Model Number : LB-50KW-AC380V
    Certification : CE, ISO9001
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 100sets per month
    Delivery Time : 20 working days
    • Product Details
    • Company Profile

    Grey Colour AC Generator Load Bank With Multi - Functional Digital Display

    Grey Colour 50KW-380V AC Generator Load Bank with Remote Control


    Intelligent AC load bank mainly used to test the capability and aging degree for high-power ups on-line, inverter and switch power for electric power, telecom department and manufacturer. It can ensure the reliability of constant power charge that adopts uniformly stepped power input, energy consumption work model and forced air-cooling model. It is of high power density, no red hot phenomenon and automatic protection function overheated. It can’t be overheated and broken when the fans stop working. The complete machine can be operated simply and maintain convenient that adopts module design. It can test voltage and current according to client’s requirements, and provide test reports for high-power AC equipment.


    With footprint size an ever vital consideration in many markets, fullde load banks provide higher voltages with integrated transformers & load banks packaged in one ISO container. Available in wide range of voltages from 600v to 33kV in both resistive and resistive-reactive configuration. Fullde will design and build load banks to your exact voltage, frequency and capacity requirements.


    Benefits of Load Bank Testing:


    • Problems discovered early can be significantly less expensive and prevents future major issues;


    • Helps to avoid wet-stacking and cleans out carbon deposits;


    • Verifies the engine cooling systems will perform while under load;


    • Provides ensure that the genset should work properly when you need it most.


    Technical Parameters for reference:


    System componentsLoad bank, resistive load,data collection, automatic control and manual control, electrical control, cooling devices and auxiliary control,Industrial machines, printer.
    Resistive load stalls(300KW)Step: 1KW
    Test voltageThree-phase AC480V;
    Test Frequency50Hz;
    Resistance tubeInsulation resistance of each resistor above DC500V 100MΩ , Pressure AC2000V 1 minute, Resistance to high temperature.
    Load connectionStar (three-phase four -wire)
    Loading precision±3%;
    Work wayContinuous work
    Working power480VAC/50Hz/Three-phase four-wire system; (reservation terminals)
    Operator terminalIPC / software, full realization of automated control
    Control modeManual control / computer software auto control
    Measured Control FunctionLoad subtraction control, extended load automatic identification synchronization control
    IPC detection functionI, V, HZ, KW, COSΦ etc.Real-time display, electrical performance testing, curves and report output, system electrical parameters monitoring, automatic data acquisition;
    Parameter recordForm through EXCEL, curves pictures saved by WORD document
    Parameter displaythree-phase voltage, three- phase current, apparent power, active power, reactive power, power factor, frequency, etc.;
    Load protectionOvervoltage, overcurrent, high temperature, air flow and fan failure protection;
    Fault alarmFan failure, load high temperature alarm
    Size750*850*1600
    Weight250kg
    Applicable ScopeFor marine diesel generator sets, land diesel generators, power inverters, UPS systems
